60V 60A Regenerative Battery Cycler for Battery Pack Aging and Capacity Testing

60V 60A Regenerative Battery Cycler for Battery Pack Aging and Capacity Testing

Product Description

ACEY-BA6060-6 60V 60A regenerative battery cycler tester is designed for programmable charging, discharging, cycling and aging tests of rechargeable battery packs and modules.

The system provides an adjustable output voltage range of 10V to 60V and a current range of 100mA to 60A. It is suitable for battery cycle life testing, capacity testing, charge/discharge characteristic testing and temperature-related performance testing.

The tester is configured with 6 completely independent test channels. Each channel can run its own programmed charge/discharge conditions, allowing multiple battery packs to be tested simultaneously under different test procedures.

With programmable CC, CC-CV, discharge, rest and cycle steps, the system supports customized test sequences and multi-layer cycle nesting. Test data including voltage, current, capacity, energy and temperature can be monitored and analyzed through the control software.

The system also adopts a bidirectional power conversion architecture for battery charge/discharge testing and integrates power modules, control modules, data acquisition, thermal management and PC-based data processing into one testing platform.

Applications

• Lithium-ion battery pack aging and cycle testing
• LiFePO4 battery pack charge/discharge testing
• Ternary lithium battery pack performance testing
• Lead-acid battery pack testing
• NiMH and NiCd battery pack testing
• Battery pack capacity verification
• Battery module production testing
• Battery cycle life testing
• Battery charge/discharge characteristic testing
• Vacuum cleaner battery pack testing
• Power tool battery pack testing
• Electric scooter battery pack testing

Product Features

• 6 independent test channels allow separate charge/discharge conditions and test programs for each channel.
• Supports adjustable 10–60V output voltage and 100mA–60A charge/discharge current for battery pack and module testing.
• Voltage and current accuracy reaches ±(0.05%FS + 0.05%RD) for stable charge/discharge measurement.
• Supports constant-current charging, CC-CV charging, constant-current discharging, resting, cycling and stopping.
• Current soft-start control reduces instantaneous current impact on batteries and connectors when a test step begins.
• Smooth CC-to-CV transition avoids current spikes during the charging process.
• Customizable work-step programming supports different test procedures and multi-layer cycle nesting.
• Test channels can automatically resume unfinished work steps after power failure, communication interruption or other abnormal stops.
• Real-time abnormal voltage and current monitoring can generate alarms and suspend the affected test channel.
• Complete test and abnormal-event logs support test process traceability.
• Supports flexible charge/discharge curve selection and combination for battery performance analysis.
• Network-based centralized management enables PC control and remote monitoring.
• Real-time test data can be monitored and uploaded to the MES system.
• Modular plug-in structure simplifies maintenance and component replacement.
• Supports software-based barcode and QR code scanning to start test procedures.
• Optional BMS communication interfaces include SMBus, I²C, HDQ, SPI, CAN and RS485.

Main Test Functions

• Battery Cycle Life Test

• Battery Capacity Test

• Charge / Discharge Characteristics Test

• Battery Temperature Characteristics Test

Programmable Test Modes

Main Technical Parameters

Product Display

FAQ

*What is the ACEY-BA6060-6 Battery Pack Charge Discharge Tester used for?
ACEY-BA6060-6 battery pack aging system is designed for battery pack charge/discharge testing, cycle aging, capacity testing and battery performance evaluation. It can be used for lithium-ion, LiFePO4, lead-acid, NiMH and NiCd battery packs.

*Does the ACEY-BA6060-6 battery pack aging machine support automatic battery cycle testing?
Yes. Users can program charge, discharge, rest and cycle steps according to the required test procedure. Multi-layer cycle nesting is supported, with up to 9999 cycles.

*Does the ACEY-BA6060-6 battery pack cycle tester support BMS communication?
Optional communication interfaces include SMBus, I²C, HDQ, SPI, CAN and RS485, with support for reading battery-related BMS parameters.

*What safety protection functions are included?
ACEY-BA6060-6 battery pack cycler provides software and hardware protection functions including over-voltage, over-current, over-discharge, over-temperature and reverse-connection protection, together with emergency cut-off and power-failure recovery functions.
