XIAMEN ACEY NEW ENERGY TECHNOLOGY CO., LTD.
Brand:
ACEYItem No.:
ACEY-G100WCompliance:
CE CertifiedWarranty:
One Year warranty with lifetime supportOrder(Moq):
1 SetPayment:
T/TProduct Origin:
ChinaLead Time:
7days100W Fiber XY Axis Visual Positioning Laser Cleaning Machine
Product Description
Laser cleaning is basically a very innovative process that is used completely contact-free mostly by means of fiber lasers to remove rust, oxides, paint and other coatings from metallic surfaces. The great advantage is that it does not change the properties of the material in the process. Laser cleaning does not require any chemicals or consumables and is therefore much more environmentally friendly and ecological than conventional processes that use acids, solvents or mechanical abrasion such as sandblasting for cleaning.
Advantage
In the production of lithium-ion batteries for electric vehicles and energy storage systems, lasers can reduce cost pressures and speed up product cycles. The coordinated laser system consisting of laser and laser deflection unit achieves unparalleled quality results even during cleaning processes. Laser systems work highly dynamically, with fully automated repeatability and absolute precision, even in the smallest spaces.
Specification
| Model No. | ACEY-G100W |
| Laser Wavelength | 1064nm |
| Laser power | 100W |
| Laser Repetition Frequency | 20-80kHz |
| Power Adjustment Range | 0-100% |
| Output Beam Quality | M2＜1.5 |
| Minimum Focused Spot Diameter | 0.005mm |
| Marking speed | ≤8000mm |
| Repeatability | ±0.1mm |
| Marking line depth | ≤0.5mm |
| Minimum character | 0.05mm |
| Marking stroke | 500*500mm |
| Laser module life | 100000小时 |
| Cooling mode | Air cooling(High precision thermostat/closed loop |
| Power supply | 220V±22V / 50Hz / 12A |
| Power | 1000 W（Power saving） |
| Dimension of whole machine | 900mm x 700mm x 1600mm |
| Weight of whole machine | 150KG |
