1-104S 300A Charge Discharge BMS Testing Equipment For Energy Storage Battery Pack

Product Description

ACEY-BP104-300A300A is a high-precision BMS protection board tester designed for 1-104 series power battery packs. It supports 300A overcharge protection testing and 300A over-discharge protection testing, with fast testing speed, high accuracy, stable data acquisition, and a user-friendly Chinese interface.

The 104S bms testing equipment can test multiple key performance items of battery protection boards, including overcharge, overcharge recovery, over-discharge, over-discharge recovery, overcurrent, internal resistance, self-consumption, short-circuit protection, protection time, balancing current, and balancing voltage. It is suitable for lithium-ion, LiFePO4, and lithium cobalt oxide battery protection boards, and can meet the testing needs of hardware BMS boards and some software BMS boards.

• High-Current Protection Testing: Supports 300A overcharge protection and 300A over-discharge protection testing, suitable for high-power battery protection board inspection.
• Wide Series Range: Compatible with 1-104S battery protection boards, meeting the testing requirements of different power battery pack configurations.
• Multiple Battery Type Selection: Supports testing mode switching for ternary lithium batteries, LiFePO4 batteries, and lithium cobalt oxide batteries.
• Fast Testing Speed and High Accuracy: Designed for efficient BMS board testing with stable performance, helping improve production inspection efficiency and product consistency.
• Laboratory Mode: Supports manual adjustment of the voltage value of any single cell, making it suitable for R&D testing, abnormal condition simulation, and detailed performance verification.
• Continuous Charge and Discharge Current Output: The equipment can continuously provide charging and discharging current, supporting long-term and repeated test requirements.
• Cycle Test Function: Supports programmable cycle testing, with cycle times from 1 to 9999 times. The system can automatically run continuous tests for different protection board indicators.
• Data Logging and Traceability: Built-in log tracking function records operation history and abnormal events during the entire testing process, making the test process traceable and easier to analyze.
• Excel Data Export: Test data can be saved as Excel files, which is convenient for quality control, data analysis, production records, and customer reporting.
• Stable RS232 Communication: The tester connects with the upper computer through an industrial-standard RS232 interface, ensuring stable and real-time data acquisition.
• Software Calibration: Supports accuracy calibration and software calibration, helping maintain test reliability during long-term use.
• Barcode Scan Start: Equipped with barcode scanning start function, suitable for production line testing and product data traceability.
• MES System Connection: Supports connection with MES systems, making it suitable for automated production management and data integration.
• Customizable Functions: Active balancing and balancing current test functions can be customized according to actual testing requirements. Communication protocol testing is also available as an optional function.

Technical Specifications

Product Details

Q1: What is the maximum series number supported by this BMS tester?
A: This BMS tester supports 1-104S battery protection board testing.

Q2: What is the maximum current supported by the bms testing equipment?
A: It supports 300A overcharge protection testing and 300A over-discharge protection testing.

Q3: What battery types can this bms tester support?
A: It supports ternary lithium batteries, LiFePO4 batteries, and lithium cobalt oxide batteries.

Q4: Can it test both hardware and software BMS boards?
A: It is mainly suitable for hardware BMS protection boards and can also test some software BMS boards.

Q5: What test items can this bms testing equipment perform?
A: It can test overcharge, overcharge recovery, over-discharge, over-discharge recovery, overcurrent, internal resistance, self-consumption, short-circuit protection, protection time, balancing current, balancing voltage, and other key BMS performance items.

Q6: Does the bms testing equipment need to connect with a computer?
A: Yes, the tester needs to be connected to a computer for operation. A general office computer can meet the basic requirements.

Q7: What communication interface does the bms tester use?
A: The equipment and computer are connected through an industrial-standard RS232 interface, ensuring stable and real-time data transmission.

Q8: Can the test data be exported?
A: Yes, test data can be saved as Excel files for quality control, data analysis, and production records.

Q9: Does the bms testing machine support barcode scanning?
A: Yes, barcode scan start function is available, which is suitable for production traceability.

Q10: Can it connect with the MES system?
A: Yes, MES system connection can be supported according to customer requirements.
